- Double row roller cam.
Double row roller cam.
d:
10-35mm
d1:
17.7-48.1
Product Detail
| Dimensions | Limiting Speed | Weight | Designation | OD | Basic load ratings | Pu | Max radial load | |||||||||
| mm | KN | kN | ||||||||||||||
| D | B | d | d1 ～ | D1 ～ | r1,2 | a | Cam rollers | Cylindrical | dyc | stc | Dyc | stc | ||||
| Min | arc | roller surface | Cr | Cor | Cor | Cor | ||||||||||
| roller surface | ||||||||||||||||
| 32 | 14 | 10 | 17.7 | 25 | 0.6 | 15 | 11000 | 0.062 | 305800C-2Z | - | 32 | 7.15 | 3.8 | 0.16 | 4.4 | 6.3 |
| 35 | 15.9 | 12 | 19.1 | 27.7 | 0.6 | 16.5 | 9500 | 0.078 | 305801C-2Z | 305701C-2Z | 35 | 9.56 | 4.9 | 0.208 | 3.8 | 5.4 |
| 40 | 15.9 | 15 | 22.1 | 30.7 | 0.6 | 18 | 8500 | 0.1 | 305802C-2Z | 305702C-2Z | 40 | 10.6 | 5.85 | 0.25 | 5.85 | 8.5 |
| 47 | 17.5 | 17 | 25.2 | 35 | 0.6 | 20 | 8000 | 0.16 | 305803C-2Z | 305703C-2Z | 47 | 13.5 | 7.8 | 0.325 | 9.3 | 13.4 |
| 52 | 20.6 | 20 | 29.4 | 40.9 | 1 | 24 | 7000 | 0.22 | 305804C-2Z | 305704C-2Z | 52 | 17.2 | 10 | 0.425 | 8.3 | 12 |
| 62 | 20.6 | 25 | 34.4 | 45.9 | 1 | 26.5 | 6000 | 0.32 | 305805C-2Z | 305705C-2Z | 62 | 19.5 | 12.5 | 0.53 | 15.3 | 21.6 |
| 72 | 23.8 | 30 | 41.4 | 55.2 | 1 | 31 | 5000 | 0.49 | 305806C-2Z | 305706C-2Z | 72 | 27.6 | 18.6 | 0.8 | 17 | 24 |
| 80 | 27 | 35 | 48.1 | 63.9 | 1.1 | 36.5 | 4300 | 0.65 | 305807C-2Z | 305707C-2Z | 80 | 33.2 | 21.2 | 0.9 | 15.6 | 22.4 |
Various kinds of bearings, steel balls and rollers, cages made from various materials, semi-finished bearing components and bearing accessories, as well as other relevant mechanical and electrical product.
